Cylinders
-
![Pneumatic Cylinder DNC 32 – ISO 6431 | Double Acting]()
- New
Pneumatic Cylinder Series DNC 32 - ISO6431 Standard (Double Acting)
€39.40Piston diameter d
AM
B
D2
D5
D7
E
EE
(G)J3
J4
KK
L2
L3
L4
L5
L6
L7
L8
SW1
SW2
VD
WH
ZB
32
22
30
12
32.5
M6
45
1/8
6
5.2
M10×1.25
40
80
4
26
22
3.3
8
10
6
16
26
120
Main characteristics:
Series: DNC
Piston diameter: 32 mm
Type: Pneumatic cylinder (Air Cylinder)
Standard: ISO 6431 / ISO 15552
Action: Double Acting
Operating medium: Filtered compressed air
Body material: Aluminium alloy
Operating pressure: approx. 0.1 – 1.0 MPa
Maximum pressure: approx. 1.35 MPa
Operating temperature: approx. -5°C to +70°C
Movement speed: 50 – 800 mm/s
Cylinder stroke: standard strokes from 50 to 1000 mm.
✔ Made to order – usually 2–3 working days.
If you need a stroke that is not among the standard options, please contact our team – we also make non-standard sizes.
-
![Pneumatic Cylinder DNC 40 – ISO 6431 | Double Acting]()
- New
Pneumatic Cylinder Series DNC 40 - ISO6431 Standard (Double Acting)
€54.60Piston diameter d
AM
B
D2
D5
D7
E
EE
(G)J3
J4
KK
L2
L3
L4
L5
L6
L7
L8
SW1
SW2
VD
WH
ZB
40
24
35
16
38
M6
54
1/4
8
6
M12×1.25
46
89
4
29.6
22
3.6
10
13
6
20
30
135
Main characteristics:
Series: DNC
Piston diameter: 40 mm
Type: Pneumatic cylinder (Air Cylinder)
Standard: ISO 6431 / ISO 15552
Action: Double Acting
Operating medium: Filtered compressed air
Body material: Aluminium alloy
Operating pressure: approx. 0.1 – 1.0 MPa
Maximum pressure: approx. 1.35 MPa
Operating temperature: approx. -5°C to +70°C
Movement speed: 50 – 800 mm/s
Cylinder stroke: standard strokes from 50 to 1000 mm.
✔ Made to order – usually 2–3 working days.
If you need a stroke that is not among the standard options, please contact our team – we also make non-standard sizes.
-
![Pneumatic Cylinder DNC Series – ISO 6431| Double Acting]()
Pneumatic Cylinder Series DNC 50 - ISO6431 Standard (Double Acting)
€68.80Piston diameter d
AM
B
D2
D5
D7
E
EE
(G)J3
J4
KK
L2
L3
L4
L5
L6
L7
L8
SW1
SW2
VD
WH
ZB
50
32
40
20
46.5
M8
64
1/4
10
9
M16x1.5
51
78
4
30
17
5
10
17
8
27
37
144
Main characteristics:
Series: DNC
Piston diameter: 50 mm
Type: Pneumatic cylinder (Air Cylinder)
Standard: ISO 6431
Action: Double Acting
Operating medium: Filtered compressed air
Body material: Aluminium alloy
Operating pressure: approx. 0.1 – 1.0 MPa
Maximum pressure: approx. 1.35 MPa
Operating temperature: approx. -5°C to +70°C
Movement speed: 50 – 800 mm/s
Cylinder stroke: This product is available in various configurations up to 2000 mm.
✔ Custom manufacturing with strokes up to 2000 mm is possible, as well as non-standard sizes according to your specific requirements.
If you need a size not included in the standard offerings, please contact our team or enter the desired length in the field below and add a model close to yours to the cart!
-
![Pneumatic Cylinder DNC Series – ISO 6431| Double Acting]()
Pneumatic Cylinder Series DNC 63 - ISO6431 Standard (Double Acting)
€85.00Piston bore d
AM
B
D2
D5
D7
E
EE
(G)J3
J4
KK
L2
L3
L4
L5
L6
L7
L8
SW1
SW2
VD
WH
ZB
63
32
45
20
56.5
M8
75
3/8
12
10
M16x1.5
54
87
4
36
17
7
10
17
8
27
37
157.5
Main specifications:
Series: DNC
Piston bore: 63 mm
Type: Pneumatic cylinder (Air Cylinder)
Standard: ISO 6431
Action: Double Acting
Operating medium: Filtered compressed air
Body material: Aluminium alloy
Operating pressure: approx. 0.1 – 1.0 MPa
Maximum pressure: approx. 1.35 MPa
Operating temperature: approx. -5°C to +70°C
Movement speed: 50 – 800 mm/s
Cylinder stroke: This product is available in various configurations up to 2000 mm.
✔ Custom manufacturing available for strokes up to 2000 mm, as well as non-standard sizes according to your specific requirements.
If you require a size not included in the standard offerings, please contact our team or enter the desired length in the field below and add a model close to yours to the cart!
-
![Pneumatic Mini Cylinder MAL 16 | Double Acting]()
- New
Pneumatic Mini Cylinder Series MAL 16 - Round Body (Double Acting)
€13.30Piston Ø A (length at stroke 0) Overall length K (rod thread) L (front cover thread) Air port 16 107 A + stroke M6×1 M16×1.5 M5 Dimensions in mm. Overall body length = A + stroke.
Main characteristics:
Series: MAL (round-body mini cylinder)
Piston diameter: 16 mm
Action: Double Acting
Operating medium: Filtered compressed air
Body material: Aluminium alloy
Operating pressure: 0.1 – 0.9 MPa
Proof pressure: 1.35 MPa
Operating temperature: -5°C to +70°C
Cushioning: rubber bumpers (fixed)
Air port: M5
Cylinder stroke: standard strokes from 25 to 500 mm.
✔ Made to order – usually 2–3 working days.
If you need a stroke that is not among the standard options, please contact our team – we also make non-standard sizes.
-
![Pneumatic Mini Cylinder MAL 20 | Double Acting]()
- New
Pneumatic Mini Cylinder Series MAL 20 - Round Body (Double Acting)
€15.10Piston Ø A (length at stroke 0) Overall length K (rod thread) L (front cover thread) Air port 20 131 A + stroke M8×1.25 M22×1.5 1/8" Dimensions in mm. Overall body length = A + stroke.
Main characteristics:
Series: MAL (round-body mini cylinder)
Piston diameter: 20 mm
Action: Double Acting
Operating medium: Filtered compressed air
Body material: Aluminium alloy
Operating pressure: 0.1 – 0.9 MPa
Proof pressure: 1.35 MPa
Operating temperature: -5°C to +70°C
Cushioning: rubber bumpers (fixed)
Air port: 1/8"
Cylinder stroke: standard strokes from 25 to 500 mm.
✔ Made to order – usually 2–3 working days.
If you need a stroke that is not among the standard options, please contact our team – we also make non-standard sizes.
